75/15 Heat Shrink Cable Repair Sleeve
- Max Cable Diameter:75mm
- Minimum Cable Diameter:15mm
- Length: Up to 1400mm
- Installation: Wraparound
- Product description: 1. Equal to Raychem/Commscope CWST 75/15 heat shrinkable wraparound cable repair sleeve; 2. Customized length,printing,logo available; 3. Easy to install and maintan;
Product introduction
Our RSBJW Wraparound Heat Shrink Cable Repair Sleeve is a protective product used to repair damaged or deteriorated cable without the need to disconnect or cut the cable. These wraparound cable repair sleeves are typically used in telecommunications, power transmission, and other industries where cables are exposed to environmental stress, mechanical damage, or wear and tear. The RSBJW wraparound cable repair sleeves can be applied directly over the damaged area of the cable, providing a sealed, waterproof, and durable protective layer.
- Fiber-reinforced: Yes
- Wraparound type: Yes
- Hot melt adhesive layer: Yes
- Thermo Adhesive Painting: Yes
Key Features of Wraparound Cable Repair Sleeves:
- -Heat-Shrinkable: Many sleeves shrink when heat is applied, creating a tight seal around the cable.
- -Waterproofing: Most sleeves provide excellent resistance to water ingress, making them ideal for outdoor use.
- -UV and Corrosion Resistance: These sleeves often come with UV-resistant materials to withstand exposure to sunlight and harsh environments.
- -Mechanical Protection: They protect cables from abrasion, chemicals, and other potential hazards.
RSBW Heat Shrink Wraparound Cable Repair Sleeve Applications:
• Cable jacket repair
• Primary insulation cover on low voltage cables
• Re-jacketing cover for power cables
RSBJW Heat Shrink Wraparound Cable Repair Sleeve Specificaton:
Description
Max. Cable Dia.
Min. Cable Dia.
Length Supplied
Remark
RSBJW 43/8-XX
43
8
100~1400mm
RSBJW 55/12-XX
55
12
100~1400mm
RSBJW 75/15-XX
75
15
100~1400mm
RSBJW 100/25-XX
100
25
100~1400mm
RSBJW 125/30-XX
125
30
100~1400mm
RSBJW 135/45-XX
135
45
100~1400mm
RSBJW 150/45-XX
150
45
100~1400mm
RSBJW 160/50-XX
160
50
100~1400mm
RSBJW 200/65-XX
200
65
100~1400mm
These heat shrinkable wraparound repaire sleeves can be customized as per request.
